Ultra High Speed Angular Contact Ball Bearings (ROBUST Series) – BNR, BER Series

BEARING
Ultra High Speed Angular Contact Ball Bearings (ROBUST Series) – BNR, BER Series

Ultra High Speed Angular Contact Ball Bearings (ROBUST Series) – BNR, BER Series

SKU库存: 9999 分类:

Ultra High Speed Angular Contact Ball Bearings (ROBUST Series) – BNR, BER Series

fa085dca-b2d3-429e-a1e4-7bf5284db2a6

Bearing Numbers Boundary Dimensions(mm) Mass (kg) (approx.) Bearing Numbers Boundary Dimensions(mm) Mass (kg) (approx.)
d D B d D B
25BNR19S 25 42 9 0.042 30BNR10S 30 55 13 0.124
25BNR19H 25 42 9 0.038 30BNR10H 30 55 13 0.116
25BNR19X 25 42 9 0.038 30BNR10X 30 55 13 0.116
25BER19S 25 42 9 0.042 30BER10S 30 55 13 0.124
25BER19H 25 42 9 0.038 30BER10H 30 55 13 0.116
25BER19X 25 42 9 0.038 30BER10X 30 55 13 0.116
30BNR19S 30 47 9 0.048 35BNR10S 35 62 14 0.164
30BNR19H 30 47 9 0.043 35BNR10H 35 62 14 0.154
30BNR19X 30 47 9 0.043 35BNR10X 35 62 14 0.154
30BER19S 30 47 9 0.048 35BER10S 35 62 14 0.164
30BER19H 30 47 9 0.043 35BER10H 35 62 14 0.154
30BER19X 30 47 9 0.043 35BER10X 35 62 14 0.154
35BNR19S 35 55 10 0.072 40BNR10S 40 68 15 0.204
35BNR19H 35 55 10 0.063 40BNR10H 40 68 15 0.193
35BNR19X 35 55 10 0.063 40BNR10X 40 68 15 0.193
35BER19S 35 55 10 0.072 40BER10S 40 68 15 0.204
35BER19H 35 55 10 0.063 40BER10H 40 68 15 0.193
35BER19X 35 55 10 0.063 40BER10X 40 68 15 0.193
40BNR19S 40 62 12 0.105 45BNR10S 45 75 16 0.259
40BNR19H 40 62 12 0.092 45BNR10H 45 75 16 0.246
40BNR19X 40 62 12 0.092 45BNR10X 45 75 16 0.246
40BER19S 40 62 12 0.105 45BER10S 45 75 16 0.259
40BER19H 40 62 12 0.092 45BER10H 45 75 16 0.246
40BER19X 40 62 12 0.092 45BER10X 45 75 16 0.246
45BNR19S 45 68 12 0.125 50BNR10S 50 80 16 0.281
45BNR19H 45 68 12 0.111 50BNR10H 50 80 16 0.266
45BNR19X 45 68 12 0.111 50BNR10X 50 80 16 0.266
45BER19S 45 68 12 0.125 50BER10S 50 80 16 0.281
45BER19H 45 68 12 0.111 50BER10H 50 80 16 0.266
45BER19X 45 68 12 0.111 50BER10X 50 80 16 0.266
50BNR19S 50 72 12 0.127 55BNR10S 55 90 18 0.414
50BNR19H 50 72 12 0.111 55BNR10H 55 90 18 0.393
50BNR19X 50 72 12 0.111 55BNR10X 55 90 18 0.393
50BER19S 50 72 12 0.127 55BER10S 55 90 18 0.414
50BER19H 50 72 12 0.111 55BER10H 55 90 18 0.393
50BER19X 50 72 12 0.111 55BER10X 55 90 18 0.393
55BNR19S 55 80 13 0.178 60BNR10S 60 95 18 0.443
55BNR19H 55 80 13 0.158 60BNR10H 60 95 18 0.419
55BNR19X 55 80 13 0.158 60BNR10X 60 95 18 0.419
55BER19S 55 80 13 0.178 60BER10S 60 95 18 0.443
55BER19H 55 80 13 0.158 60BER10H 60 95 18 0.419
55BER19X 55 80 13 0.158 60BER10X 60 95 18 0.419
60BNR19S 60 85 13 0.19 65BNR10S 65 100 18 0.472
60BNR19H 60 85 13 0.17 65BNR10H 65 100 18 0.447
60BNR19X 60 85 13 0.17 65BNR10X 65 100 18 0.447
60BER19S 60 85 13 0.19 65BER10S 65 100 18 0.472
60BER19H 60 85 13 0.17 65BER10H 65 100 18 0.447
60BER19X 60 85 13 0.17 65BER10X 65 100 18 0.447
65BNR19S 65 90 13 0.204 70BNR10S 70 110 20 0.645
65BNR19H 65 90 13 0.181 70BNR10H 70 110 20 0.605
65BNR19X 65 90 13 0.181 70BNR10X 70 110 20 0.605
65BER19S 65 90 13 0.204 70BER10S 70 110 20 0.645
65BER19H 65 90 13 0.181 70BER10H 70 110 20 0.605
65BER19X 65 90 13 0.181 70BER10X 70 110 20 0.605
70BNR19S 70 100 16 0.328 75BNR10S 75 115 20 0.679
70BNR19H 70 100 16 0.292 75BNR10H 75 115 20 0.638
70BNR19X 70 100 16 0.292 75BNR10X 75 115 20 0.638
70BER19S 70 100 16 0.328 75BER10S 75 115 20 0.679
70BER19H 70 100 16 0.292 75BER10H 75 115 20 0.638
70BER19X 70 100 16 0.292 75BER10X 75 115 20 0.638
75BNR19S 75 105 16 0.348 80BNR10S 80 125 22 0.921
75BNR19H 75 105 16 0.31 80BNR10H 80 125 22 0.867
75BNR19X 75 105 16 0.31 80BNR10X 80 125 22 0.867
75BER19S 75 105 16 0.348 80BER10S 80 125 22 0.921
75BER19H 75 105 16 0.31 80BER10H 80 125 22 0.867
75BER19X 75 105 16 0.31 80BER10X 80 125 22 0.867
80BNR19S 80 110 16 0.366 85BNR10S 85 130 22 0.962
80BNR19H 80 110 16 0.326 85BNR10H 85 130 22 0.906
80BNR19X 80 110 16 0.326 85BNR10X 85 130 22 0.906
80BER19S 80 110 16 0.366 85BER10S 85 130 22 0.962
80BER19H 80 110 16 0.326 85BER10H 85 130 22 0.906
80BER19X 80 110 16 0.326 85BER10X 85 130 22 0.906
85BNR19S 85 120 18 0.527 90BNR10S 90 140 24 1.241
85BNR19H 85 120 18 0.456 90BNR10H 90 140 24 1.155
85BNR19X 85 120 18 0.456 90BNR10X 90 140 24 1.155
85BER19S 85 120 18 0.527 90BER10S 90 140 24 1.241
85BER19H 85 120 18 0.456 90BER10H 90 140 24 1.155
85BER19X 85 120 18 0.456 90BER10X 90 140 24 1.155
90BNR19S 90 125 18 0.552 95BNR10S 95 145 24 1.298
90BNR19H 90 125 18 0.48 95BNR10H 95 145 24 1.209
90BNR19X 90 125 18 0.48 95BNR10X 95 145 24 1.209
90BER19S 90 125 18 0.552 95BER10S 95 145 24 1.298
90BER19H 90 125 18 0.48 95BER10H 95 145 24 1.209
90BER19X 90 125 18 0.48 95BER10X 95 145 24 1.209
95BNR19S 95 130 18 0.571 100BNR10S 100 150 24 1.245
95BNR19H 95 130 18 0.497 100BNR10H 100 150 24 1.253
95BNR19X 95 130 18 0.497 100BNR10X 100 150 24 1.253
95BER19S 95 130 18 0.571 100BER10S 100 150 24 1.245
95BER19H 95 130 18 0.497 100BER10H 100 150 24 1.253
95BER19X 95 130 18 0.497 100BER10X 100 150 24 1.253
100BNR19S 100 140 20 0.77 105BNR10S 105 160 26 1.698
100BNR19H 100 140 20 0.673 105BNR10H 105 160 26 1.585
100BNR19X 100 140 20 0.673 105BNR10X 105 160 26 1.585
100BER19S 100 140 20 0.77 105BER10S 105 160 26 1.698
100BER19H 100 140 20 0.673 105BER10H 105 160 26 1.585
100BER19X 100 140 20 0.673 105BER10X 105 160 26 1.585
105BNR19S 105 145 20 0.795 110BNR10S 110 170 28 2.133
105BNR19H 105 145 20 0.693 110BNR10H 110 170 28 1.996
105BNR19X 105 145 20 0.693 110BNR10X 110 170 28 1.996
105BER19S 105 145 20 0.795 110BER10S 110 170 28 2.133
105BER19H 105 145 20 0.693 110BER10H 110 170 28 1.996
105BER19X 105 145 20 0.693 110BER10X 110 170 28 1.996
110BNR19S 110 150 20 0.838 120BNR10S 120 180 28 2.286
110BNR19H 110 150 20 0.733 120BNR10H 120 180 28 2.139
110BNR19X 110 150 20 0.733 120BNR10X 120 180 28 2.139
110BER19S 110 150 20 0.838 120BER10S 120 180 28 2.286
110BER19H 110 150 20 0.733 120BER10H 120 180 28 2.139
110BER19X 110 150 20 0.733 120BER10X 120 180 28 2.139
120BNR19S 120 162 22 1.124 130BNR10S 130 200 33 3.408
120BNR19H 120 162 22 0.949 130BNR10H 130 200 33 3.194
120BNR19X 120 162 22 0.949 130BER10S 130 200 33 3.408
120BER19S 120 162 22 1.124 130BER10H 130 200 33 3.194
120BER19H 120 162 22 0.949 140BNR10S 140 210 33 3.647
120BER19X 120 162 22 0.949 140BNR10H 140 210 33 3.419
130BNR19S 130 180 24 1.477 140BER10S 140 210 33 3.647
130BNR19H 130 180 24 1.265 140BER10H 140 210 33 3.419
130BER19S 130 180 24 1.477 150BNR10S 150 225 35 4.405
130BER19H 130 180 24 1.265 150BNR10H 150 225 35 4.129
140BNR19S 140 190 24 1.567 150BER10S 150 225 35 4.405
140BNR19H 140 190 24 1.353 150BER10H 150 225 35 4.129
140BER19S 140 190 24 1.567
140BER19H 140 190 24 1.353
150BNR19S 150 210 28 2.459
150BNR19H 150 210 28 2.139
150BER19S 150 210 28 2.459
150BER19H 150 210 28 2.139

Packaging Details:

1.Tube packing.

2.Plastic bag +carton

3.According to customer requirement
Delivery Detail: In general 5-10 days after we received your orders
