| BEARING | INNER | OUTER | WIDTH | LIMMITED SPEED | WEIGHT | ||||
| CODE | d | D | B | GREASE | OIL | KG | |||
| MM INCH | MM INCH | MM INCH | R/M | R/M | |||||
| 87500 | 10 | 0.3937 | 30 | 1.1811 | 9 | 12.7 | 25000 | 30000 | 0.035 |
| 87501 | 12 | 0.4724 | 32 | 1.2598 | 10 | 12.7 | 22000 | 26000 | 0.044 |
| 87502 | 15 | 0.5906 | 35 | 1.378 | 11 | 12.7 | 19000 | 23000 | 0.049 |
| 87503 | 17 | 0.6693 | 40 | 1.6535 | 12 | 14.288 | 18000 | 21000 | 0.07 |
| 87504 | 20 | 0.7874 | 47 | 1.8504 | 14 | 15.875 | 16000 | 18000 | 0.108 |
| 87505 | 25 | 0.9843 | 52 | 2.047 | 15 | 15.875 | 13000 | 15000 | 0.133 |
| 87506 | 30 | 1.1811 | 62 | 2.4409 | 16 | 20 | 11000 | 13000 | 0.23 |
| 87507 | 35 | 1.3779 | 72 | 2.8346 | 17 | 21 | 9800 | 11000 | 0.321 |
| 87508 | 40 | 1.5748 | 80 | 3.1496 | 21 | 24 | 8700 | 10000 | 0.486 |
| 87509 | 45 | 1.7716 | 85 | 3.3465 | 21 | 24 | 7800 | 9200 | 0.545 |
| 87510 | 50 | 1.9685 | 90 | 3.5433 | 22 | 26 | 7100 | 8300 | 0.59 |
| 87602 | 15 | 0.5906 | 42 | 1.6535 | 13 | 15 | 17000 | 21000 | 0.088 |
| 87603 | 17 | 0.6693 | 47 | 1.8504 | 14 | 16 | 16000 | 19000 | 0.117 |
| 87604 | 20 | 0.7874 | 52 | 2.0472 | 15 | 19 | 14000 | 17000 | 0.16 |
| 87605 | 25 | 0.9843 | 62 | 2.4409 | 17 | 21 | 12000 | 14000 | 0.272 |
| 87606 | 30 | 1.1811 | 72 | 2.8346 | 19 | 23 | 10000 | 12000 | 0.404 |
| 87607 | 35 | 1.3779 | 80 | 3.1496 | 21 | 25 | 8800 | 10000 | 0.509 |
| 87608 | 40 | 1.5748 | 90 | 3.5433 | 23 | 27 | 7800 | 9200 | 0.708 |
| 87609 | 45 | 1.7716 | 100 | 3.937 | 25 | 30 | 7000 | 8200 | 0.913 |
| 88505 | 25 | 0.9843 | 52 | 2.0472 | 15 | 16.8 | 13000 | 15000 | 0.147 |
| 88506 | 30 | 1.1811 | 62 | 2.4409 | 16 | 24 | 11000 | 13000 | 0.235 |
| 88507 | 35 | 1.378 | 72 | 2.8346 | 17 | 25 | 9800 | 11000 | 0.33 |
| 88508 | 40 | 1.5748 | 80 | 3.1496 | 21 | 27 | 8700 | 10000 | 0.448 |
| 88509 | 45 | 1.7716 | 85 | 3.3465 | 21 | 27 | 7800 | 9200 | 0.498 |
| 88510 | 50 | 1.9685 | 90 | 3.5433 | 22 | 30 | 7100 | 8300 | 0.554 |
| 88511 | 55 | 2.1654 | 100 | 3.937 | 23 | 31 | 6400 | 7600 | 0.76 |
| 88512 | 60 | 2.362 | 110 | 4.3307 | 22 | 36 | 6000 | 7000 | 0.963 |
1.Tube packing.
2.Plastic bag +carton
3. netural packing
4.industrial packaging
5. A single color box packing, industrial packaging, typing according to customer’s
requirements
6. Play tray, iron, wood. tray
7.According to your requirement
Delivery Detail: In general 5-10 days after we received your orders
